Product ID:
PROD0010
Biconcave Lens
Negative focal length biconcave lenses, used for beam expanders, optical imaging, and laser systems.
Custom Sizes Available
ISO 9001 Certified
Fast Delivery
Quality Guaranteed
Need Help?
Contact our sales team for specifications, customization, and quotes.
info@novacomponent.comTechnical Specifications
| Structure | Biconcave Lens |
|---|---|
| Material | Optical Glass, UVFS, Ge, Silicon, CaF2, MgF2, ZnSe, ZnS, Sapphire |
| Available Diameter | 0.5mm to 600mm |
| Diameter Tolerance | +0.00/-0.01mm or customer design |
| Surface Quality | 10-5 |
| Surface Irregularity | λ/10 PV @ 632.8nm or customer design |
| Thickness Tolerance | +0/-0.01mm |
| Clear Aperture | > 90% of diameter |
| Chamfer | 0.05-0.5mm × 45° |
| Coating | Single MgF2, Multi-layer AR coating |
| Effective Focal Length | Range from -20 to -250mm (SD4A series) |
Product Description
Negative focal length biconcave lenses, used for beam expanders, optical imaging, and laser systems.
