Achromatic Doublet Lens
Achromatic lenses consist of two lens elements cemented together, mainly used to reduce spherical aberration, coma, and chromatic aberration.
Need Help?
Contact our sales team for specifications, customization, and quotes.
info@novacomponent.com| Structure | Achromatic Doublet Lens |
|---|---|
| Material | Optical Glass, UVFS, Ge, Silicon, CaF2, MgF2, ZnSe, ZnS, Sapphire |
| Available Diameter | 0.5mm to 600mm |
| Diameter Tolerance | +0.00/-0.01mm or customer design |
| Surface Quality | 10-5 |
| Surface Irregularity | λ/10 PV @ 632.8nm or customer design |
| Thickness Tolerance | +0/-0.01mm |
| Clear Aperture | > 90% of diameter |
| Chamfer | 0.05-0.5mm × 45° |
| Coating | Single MgF2, Multi-layer AR coating (A: 350-650nm, B: 650-1050nm, C: 1050-1585nm, D: Customer design) |
Product Description
Achromatic lenses consist of two lens elements cemented together, mainly used to reduce spherical aberration, coma, and chromatic aberration.
